Description
- Brand: Hikvision
- Model: DS-2CD1047G2H-LIUF/SL
- Type: Surveillance Camera
-
Camera
- Image Sensor: 1/3" Progressive Scan CMOS
- Resolution: Max. 4MP, 2560 × 1440
- Illumination: Min. Color: 0.001 Lux @ (F1.0, AGC ON), 0 Lux with Light
- Shutter Time: 1/3 s to 1/100,000 s
- Day/Night: IR Cut Filter
- Angle Adjustment: Pan: 0° to 355°, tilt: 0° to 90°, rotate: 0° to 355°
- Lens: 4mm, Fixed Focal Lens
-
Field of View: Horizontal FOV 80°, Vertical FOV 43°, Diagonal FOV 93°
- Lens Mount: M12
- Light Type: IR, White Light
- Light Range: Up to 30m
- IR Wavelength: 850 nm
- Day/Night Switch: Day, Night, Auto, Schedule
- Support WDR: Yes, 120dB
- Image Enhancement: BLC,HLC,3D DNR
-
Video & Audio
- Main Stream: 50 Hz: 20 fps (2560 × 1440) 25 fps (1920 × 1080, 1280 × 720) 60 Hz: 20 fps (2560 × 1440) 24 fps (1920 × 1080, 1280 × 720)
-
Sub-Stream: 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360) 60 Hz: 24 fps (1280 × 720, 640 × 480, 640 × 360)
- Video Compression: Main Stream: H.265+/H.265/H.264+/H.264, Sub-Stream: H.265/H.264/MJPEG
-
Video Bit Rate: 32 Kbps to 8 Mbps
- Environment Noise Filtering: Yes
-
Interface
- Built-in Mic: Yes
- Alarm: Yes, Motion Detection
- Ethernet Interface: 1x RJ45 10 M/100 M Self-Adaptive Ethernet Port
-
Network
- Protocols: TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, RTCP, NTP, IPv4, IPv6, IGMP, UDP, QoS,
FTP, SMTP, UPnP -
Simultaneous Live View: Up to 6 Channels
-
API: Yes
- User/Host: Up To 32 Users 3 User Levels: Administrator, Operator, and User
- Protocols: TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, RTCP, NTP, IPv4, IPv6, IGMP, UDP, QoS,
-
General
- Operating Conditions: -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (Non-Condensing)
- Protection Level: IP67
- Power Supply: 12 VDC ± 25%
- Power Consumption: Max. 7.2W, PoE: IEEE 802.3af, Class 3, max. 8.7 W
- Material: Metal, Plastic
- Dimensions: 179 × 69.1 × 67.4 mm
- Weight: Approx. 320 g
